FRO900 Fingerprint Scanner
- International Standard
- High Image Quality
- Strong Adaption
- Cloud Platform
- OS Support
- SDK
Heavy-duty. Accurate. Reliable. The ARATEK FRO900 is built for the largest jobs under the toughest conditions. It
uses advanced biometric technology to handle for massive scale applications such as National ID, voter
registration, census, and other big government projects.
FEATURES
- FBI Appendix-F Certified
- International Standard
ISO19794-2, ISO19794-4, ANSI 378, ANSI 381 and WSQ supported - High Image Quality
Optical fingerprint technology with superior image quality - Strong Adaption
Good adaption for dry, moist and rough fingerprints - Correction and Authentication
Support auto correction and 360 degree rotation authentication - Cloud Platform
Seamlessly join in Aratek TrustLinkTM biometrics authentication platform - OS Support
Windows2000, XP, Vista, Windows 7 / 8 / 10, Android and other embedded systems - SDK
Comprehensive software development kit is available for development and integration
SPECIFICATION
| Physical Parameter | |
| Dimension | 148*152*115mm (L*W*H) |
| Performance Parameter | |
| Capture Mode | Optical Touch |
| Platen Size | 81.0*86.0 mm |
| Sensing Area | Press: 81.2*76.2 mm
Roll: 40.6*40.6 mm |
| Fingerprint Image Size | Flat Image Size: 1600*1500 pixels Roll Image Size: 800 x 800 pixels |
| Image Resolution | 500 dpi |
| Gray level | 256 level |
| Communication Mode | |
| Communication Interface | USB 2.0 |
| Operation Environment | |
| Work Voltage | 5.0 V (USB power supply) |
| Work Current | ≤500mA |
| Temperature |  0°C~50°C |
| Humidity | 10~90%(Non condensing) |
| ESD | Contact: ± 4KV Air: ± 8KV |
| Supported OS | |
| Windows | Â XP / 7 / 8 / 10, Android, Linux |
Applications
- Voter ID
- National ID
- Finance and Banking
- Telecommunication
- Healthcare
- Law Enforcement
